Bitumen Emulsifying Machine
CXTCM Bitumen Emulsifying Machine is a new product to match use in asphalt mixing plant site or alone. It has new crafts and meets clients’ requirements. The finished products will be used for highway construction.
Send Inquiry
Product Description
Emulsifying Bitumen Machine is developed and manufactured by CXTCM after constantly pursuing new crafts and improving the old as well as taking users’ advices and needs into consideration. Under standard conditions, its rated productivity is 6t/h.
Main parts of Bitumen Emulsifying Machine: one main machine body; one hot-water tank; one emulsion agitator tank; one bitumen tank; one finished material storage tank(for transitory purpose); one speed-adjustable bitumen tank; one speed-adjustable emulsion pump; one emulsifying machine; one finished material conveying pump; one electric control cabinet and related heating pipes of thermal conduct oil, bitumen conveying pipes and emulsion liquid conveying pipes.
Main structure of Emulsifying Bitumen Machine: this machine is integral structure to facilitate the transportation and installation. What’s more, the overall dimension of the largest part can meet the requirement of a 40QH container.
Operating principle of Emulsifying Bitumen Machine: this is to perfect the ratio of bitumen and emulsion. There are two frequency converters to regulate the rotate speed of the bitumen pump and emulsion pump to control the output quantity respectively. Then the bitumen will be grinded and sheared by emulsifying machine into small particles suspended in the emulsion liquid, forming emulsified bitumen which can be used at site.
Sketch map of emulsifying bitumen（1）
Sketch map of emulsifying bitumen（2）
Bitumen Emulsifying Machine Parameter (Specification)
|
Name |
Mode/Specification/Dimension |
Remarks |
||
|
Model |
|
LRS-6 |
LRS-10 |
|
|
Max. productivity |
|
6 t/h |
10 t/h |
|
|
Main frame |
|
L x W x H=7900 x2000 x 2200 mm |
|
|
|
Hot-water tank |
Capacity |
4.0 m3 |
6.0 m3 |
|
|
Dimension |
L x W x H=1800 x 2000 x 2200 mm |
|
|
|
|
Emulsion agitator tank |
Capacity |
3.8 m3 |
6.0 m3 |
|
|
Dimension |
L x W x H=1600 x 2000 x 1800 mm |
|
|
|
|
Bitumen tank |
Capacity |
4.5m3 |
6.0 m3 |
|
|
Dimension |
L x W x H=1900 x 2000 x 2000 mm |
|
|
|
|
Finished material tank |
Capacity |
1.5m3 |
3.0 m3 |
|
|
Dimension |
L x W x H=1600 x 1000 x 1000 mm |
|
|
|
|
Bitumen pump |
Mode |
LCB-3A |
|
Thermal conduct-oil insulated |
|
Motor |
Y160M-4-3KW |
|
Speed control by frequency conversion |
|
|
Flow |
3t/h |
|
|
|
|
Emulsion Pump |
Mode |
LCB-3B |
|
|
|
Motor |
Y160M-4-3KW |
|
Speed control by frequency conversion |
|
|
Flow |
3t/h |
|
|
|
|
Emulsifying machine |
Mode |
RH-6 |
|
|
|
Motor |
Y180M2-2-22KW |
|
|
|
|
Flow |
6t/h |
|
|
|
|
Finished material conveying pump |
Mode |
3QGB60X2-46 |
|
|
|
Motor |
Y132M164KW |
|
|
|
|
Flow |
9.8 m3/h |
|
|
|
|
Electric control cabinet |
Dimension |
L x W x H=700 x 450 x 1500 mm |
|
|
Reserve the right to change the parameters without prior notice.
Bitumen Emulsifying Machine Production Process Diagram
